Electronic sensors
From CAD assembly to photorealistic product visual
Technically detailed engineering data, unsuitable for customer-facing use, refined into clean presentation-ready visuals without losing a millimetre of accuracy.
- Client
- IPF Electronic GmbH
- Industry
- Electronic sensors
- Scope
- 3D visualization
- Input
- CAD data (STEP / IGES)
- Output
- High-fidelity renders
- Published
- With client permission
Source data, and the delivered visual.
Drag to move between what arrived and what shipped.
Client reference imageDelivered render
Drag the handle, or use the arrow keys, to compare.
The product animation.
A 9-second turntable film from the same model: the display, keypad and M12 connector in one continuous move, ready for product pages and trade show screens.
Every asset delivered for IPF Electronic GmbH.
Select any image to view it full size.
Challenge, approach, result.
- ChallengeThe client needed clear, high-quality visuals of an electronic sensor device for presentation and marketing. The existing CAD data was technically detailed but not suitable for visual communication or customer-facing use.
- ApproachWe refined the CAD geometry, applied accurate materials and built a lighting setup that highlights the product’s form, connectors and surface details. The focus throughout was keeping technical accuracy while improving visual clarity, not one at the expense of the other.
- ResultCatalogue and presentation visuals that match the engineering exactly, ready for datasheets, distributor portals and the company website.
